Taoxing Automatic CCD Screen Printing Machine High Precision Flat Printer CCD4060

Taoxing Automatic CCD Screen Printing Machine High Precision Flat Printer CCD4060

Taoxing  Automatic CCD Screen Printing Machine High Precision Flat Printer CCD4060
Taoxing  Automatic CCD Screen Printing Machine High Precision Flat Printer CCD4060Taoxing  Automatic CCD Screen Printing Machine High Precision Flat Printer CCD4060Taoxing  Automatic CCD Screen Printing Machine High Precision Flat Printer CCD4060Taoxing  Automatic CCD Screen Printing Machine High Precision Flat Printer CCD4060Taoxing  Automatic CCD Screen Printing Machine High Precision Flat Printer CCD4060
Fully automatic CCD registering screen printing machine is suitable for precise screen printing capacity type touch panel, ITO conductive glass, ITO conductive film, blood sugar tester, EL panel, etc.
CategoriesAutomatic Flat Screen Printing Machine
BrandTAOXING Screen Printing Machines Manufacturer
ModelTX-CCD4060
ModelTX-4060CCD
Max printing area400X600mm
Table size500x700mm
Printing Speed400Pcs/h
Max screen frame750x1080mm
Stacking Height300mm
Work-Piece Thickness0.1-2mm
Machine Weight2200kg
Worktable Displacement±5mm
Power SupplyAC380V/50Hz
Machine Dimension3500*1100*2050mm
Machine Weight950KG
FOB portShanghai or Ningbo
Terms of PaymentT/T
Download
Update TimeDec 14,2024
Detail Information
Introduction Fully Automatic CCD Registering Screen Printing Machine
Fully automatic CCD screen printing machine
Automatic CCD image registration screen printer for highest demands, equipped with CCD camera system and movable printing table for high-quality printing on flat materials such as EL foils, LGP boards, BEF films, touch screens, membrane switches, flexible printed circuits, etc.
* For product and process development
* Designed for selective coatings such as printed electronics, solar cells, RFID and organic electronics
* Precise alignment of single and multi-layers
* Minimal setup time for screen, substrate and print media
* Simple parameter control and precise documentation
Features
A. Full automatic system, with auto loading and unloading device for improving production yield rate.
B. PLC programming, touching screen, simple to operate, easy to use.
C. LED Control panel is available for any position by rotating the hunger, easy to operate.
D. CCD auto-alignment system ensure accurate printing, the aligning accuracy within +0.01mm, to provide excellent function.
E. Top servo motors drive printing fast and smooth, stable and quiet.
F. Multi-valued image processing
G. Machine components top configuration
H. Anti-static bar and anti-dust rollers is optional.
I. Fault self detection system with emergency switch and safety protection, and alarm light, etc.
Specification   Fully automatic CCD registering screen printing machine
Model
TX-CCD4060
Table Size
500x700mm
Substrate Thickness
0.1-2mm
Max Printing Area
400*600mm
Min Printing Area
400x400mm
Productivity
400 pcs/h
Max Frame O/D Size
750x1080mm
Stacking Height
300mm
Worktable Displacement
±5mm
Power Consumption
5.5kW
Air Exhaustion
15L/min
Machine Dimension
3500*1100*2050MM
Machine Weight
950kg
Details picture
Application  Fully automatic CCD registering screen printing machine
Membrane switch
Membrane Switch
mobile phone screen
mobile phone screen
Flexible circuit board
Flexible circuit board
